BMW 3: General information
Symbols used
The following symbol is used in this document to facilitate better comprehension or to draw attention to very important information:
Contains important safety information and information that needs to be observed strictly in order to guarantee the smooth operation of the system.
Originally Published: April 2019
BMW Group vehicles meet the requirements of the highest safety and quality standards. Changes in requirements for environmental protection, customer benefits and design render necessary continuous development of systems and components. Consequently, there may be discrepancies between the contents of this document and the vehicles available in the training course.
The information contained in the training course materials is solely intended for participants in this training course conducted by BMW Group Technical Training Centers, or BMW Group Contract Training Facilities.
This training manual or any attached publication is not intended to be a complete and all inclusive source for repair and maintenance data. It is only part of a training information system designed to assure that uniform procedures and information are presented to all participants.
For changes/additions to the technical data, repair procedures, please refer to the current information issued by BMW of North America, LLC, Technical Service Department.
Additional sources of information
Further information on the individual topics can be found in the following:
- Owner's Handbook
- Integrated Service Technical Application
- Aftersales Information Research (AIR)
Introduction
As an innovative plug-in hybrid, the new BMW 330e Sedan combines the best of two worlds and exudes special innovative strength and modern sportiness. The BMW eDrive electric motor enables extremely efficient driving with zero local emissions. At the same time, the BMW 330e Sedan is characterized by its typical BMW driving dynamics.
When the electric drive and the BMW TwinPower Turbo 4-cylinder gasoline engine work together, the vehicle achieves particularly high agility and an impressive performance.
Basic information on the topic of high-voltage technology can be found in the listed documents:
Basic information
- I01 Complete Vehicle Reference Manual
- High-voltage Safe Working Practices Reference Manual
Only Service employees who satisfy all the prerequisites are permitted to work on the designated high-voltage components: suitable qualifications, compliance with the safety rules, procedure following the exact repair instructions.
